1U Thickness 8 Way Cabinet PDU with Switch Control Power Distribution Unit for Data Centers

1U Thickness 8 Way Cabinet PDU with Switch Control Power Distribution Unit for Data Centers
1U Thickness 8 Way Cabinet PDU with Switch Control Power Distribution Unit for Data Centers
Basic Information
Brand Name: Zion communication
Model Number: 1U 8 way Cabinet PDU
Get Best Price Contact Now
Detail Information
The Length Of Size: 19 Inch Rated Current: 10A
Thickness Of The Unit: 1U Environment Temperature: -40~ +70°C
Highlight:

8 Way Cabinet PDU

,

Cabinet PDU 250V 10A

,

1U Thickness Cabinet PDU

Product Description

1U 8 Way Cabinet PDU with Switch IEC 250V 10A C13 Power Distribution Unit
1U Thickness 8 Way Cabinet PDU with Switch Control Power Distribution Unit for Data Centers 0
Product Information
Zion Code Zion Description
PDU-7245324(ZC-1U08-K-C13) 1U 8 way Cabinet PDU with Switch IEC 250V,10A C13
Applications
  • Banking, securities, universities, municipal administration, medical care, electric power and other fields
  • Data Center
  • Enterprise networking
PDU Basic Module Overview
1U Thickness 8 Way Cabinet PDU with Switch Control Power Distribution Unit for Data Centers 1
Switch Control
Control the power on and off of the PDU to manage data system operation.
Modular Functional Design
All functional modules feature modular construction with socket modules compliant with global standards. Components use phosphor bronze for elasticity, wear-resistance, and corrosion resistance, ensuring reliable contact with 5000+ plug cycles.
Cable Options
Available in 10A 3*1.5mm², 16A 3*2.5mm², 25A 3*4mm², and 32A 3*6mm² cables.
Custom Branding
ODM/OEM logo printing available according to customer requirements.
Aluminum Alloy Housing
High-strength aluminum alloy shell ensures durability and efficient heat dissipation.
Flexible Installation
Designed for installation in any orientation (360° rotation capability).
Power Input Options
Available in left/right-side input, front/rear input, single/double side input, and socket input configurations.
Technical Specifications
Countries Socket Type: 10A C13
Rated Current: 10A
Rated Voltage: 250VAC 50/60Hz
Max. Continuous Operating Voltage: 320VAC
Unit Thickness: 1U
Output Modules: 8 way
Length: 19 inch
Alternative Filtration: Highly efficient
Vendor Name: Zion Communication / Hello Signal
Incidental Function: Switch
Environment Temperature: -40°C to +70°C
Material: Uninflammable PC module UL94V-0, Aluminum alloy shell
Fire Resistance: UL 94V-0
Color: Black
OEM/ODM: YES
Packing: 1pc/plastic bag/inner box, 25pcs/carton
Related PDU Products
Zion Code Name Code Description
7245301ZC-1U03-3P-WN1U 3 way Cabinet PDU with 3P air circuit breaker 250V,10A Universal
7245302ZC-1U06-K-WN1U 6 way Cabinet PDU with Switch 250V,10A Universal
7245303ZC-1U06-K-3D-WN1U 6 way Cabinet PDU with Switch and 3D Light 250V,10A Universal
7245304ZC-1U08-K-G-WN1U 8 way Cabinet PDU with Switch and Overload protection 250V,10A Universal
7245305ZC-1U06-P-WN1U 6 way Cabinet PDU with Switch and Overload protection 250V,10A Universal
7245306ZC-1U06-K-D-U-WN1U 6 way Cabinet PDU with S1P air circuit breaker 250V,10A Universal
7245307ZC-1U06-Z-P-WN1U 6 way Cabinet PDU with Power Light and 1P air circuit breaker 250V,10A Universal
7245308ZC-1U06-L-WN161U 6 way Cabinet PDU with Earth Leakage protection 250V,16A Universal
7245309ZC-1U06-L-Z-WN161U 6 way Cabinet PDU with Earth Leakage protection and Power Light 250V,16A Universal
7245310ZC-1U08-K-G-WN161U 8 way Cabinet PDU with Switch and Overload protection 250V,16A Universal
7245311ZC-1U03-K-WN161U 3 way Cabinet PDU with Switch 250V,16A Universal
7245312ZC-1.5U06-L-WN161.5U 6 way Cabinet PDU with Earth Leakage protection 250V,16A Universal
7245313ZC-1U12-Z-UK1U 12 way Cabinet PDU with Power Light 250V,13A UK
7245314ZC-1.5U06-k-G-D-UK1.5U 6 way Cabinet PDU with Switch and Overload protection and 3D Light 250V,13A UK
7245315ZC-1U06-K-G-UK1U 6 way Cabinet PDU with Switch and Overload protection 250V,13A UK
7245316ZC-1U08-UK1U 8 way Cabinet PDU with 250V,13A UK
7245317ZC-1U07-K-G-UK1U 7 way Cabinet PDU with Switch and Overload protection 250V,13A UK
7245318ZC-1U08-K-G-UL1U 8 way Cabinet PDU with Switch and Overload protection 125V,15A UL
7245319ZC-1.5U09-K-UL1.5U 9 way Cabinet PDU with Switch 125V,15A UL
7245320ZC-1.5U10-G-UL1.5U 10 way Cabinet PDU with Overload protection 125V,15A UL
7245321ZC-1.5U12-K-UL1.5U 12 way Cabinet PDU with Switch 125V,15A UL
7245322ZC-1U06-K-G-U-UL1U 6 way Cabinet PDU with Switch and Overload protection and USB 125V,15A UL
7245323ZC-1U10-K-C131U 10 way Cabinet PDU with Switch IEC 250V,10A C13
7245324ZC-1U08-K-C131U 8 way Cabinet PDU with Switch IEC 250V,10A C13
7245325ZC-1U06-K-G-FRA1U 6 way Cabinet PDU with Switch and Overload protection 250V,16A France
7245326ZC-1.5U08-FRA1.5U 8 way Cabinet PDU 250V,16A France
7245327ZC-1U12-K-G-GER1U 12 way Cabinet PDU with Switch and Overload protection 250V,16A German
7245328ZC-1U08-K-G-GER1U 8 way Cabinet PDU with Switch and Overload protection 250V,16A German
7245329ZC-1.5U06-K-3D-GER1.5U 6 way Cabinet PDU with Switch and 3D Light 250V,16A German
