| Place of Origin: | China |
|---|---|
| Brand Name: | hellosignal |
| Certification: | UL, CE, RoHS |
| Model Number: | CCTV SURVEILLANCE CABLE |
| Minimum Order Quantity: | 30 KM |
| Packaging Details: | 500FT, 1000FT Wooden Reel or Spool in Box |
| Delivery Time: | 25 working days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 3000KM / Month |
| Conductor: | Bare Copper | Dielectric: | Foam FEP |
|---|---|---|---|
| Shield: | BC-Braid(47%) | Jacket: | PVC/PE/LSZH |
| Power Wire Conductor: | BC | Power Wire Diameter Of Insulation: | HDPE (Red,Black) |
|
RG59K + 2C0.5 Figure 8 NO.7102035 |
||||||||
| Similar Type: | ||||||||
| Coaxial Cable | Power Cores | |||||||
| Catalog No. |
Cond.Type &Nom.D.C.R |
Dielectric | Shielding& %Coverage |
Jacket | Power Wire Cond.Type | Power wire OD of insulation |
Jacket | Nom. Capacitance |
| RG59 B/U +2C0.50 Figure 8 NO.7102036 |
0.58mm (SOL) BC 54 Ω/km |
Solid PE |
BC Braid 95% |
6.00mm PVC/PE/LSZH |
2x (16*0.2mm BC ) |
1.9mm HDPE (Red,Black) |
5.05mm PVC/PE/ LSZH |
67±2 pF/m |
| RG59 B/U +2C0.50 CCA Figure 8 NO.7102037 |
0.58mm (SOL) BC 54 Ω/km |
Solid PE |
CCA Braid 95% |
6.00mm PVC/PE/LSZH |
2x (16*0.2mm CCA ) |
1.9mm HDPE (Red,Black) |
5.05mm PVC/PE/ LSZH |
67±2 pF/m |
| RG59 Micro +2C0.75 Figure 8 NO.7102040 |
7*0.18mm (SOL) BC 54 Ω/km |
Solid PE |
CCA Braid 95% |
4.05mm PVC/PE/LSZH |
2x (16*0.2mm CCA ) |
1.9mm HDPE (Red,Black) |
5.05mm PVC/PE/ LSZH |
52±3 pF/m |
| RG59 B/U +2C0.50 CCA Figure 8 NO.7102041 |
0.5mm (SOL) BC 87.6 Ω/km |
Foam FEP |
1.Al/PET-Foil 2.CCA -Braid 50% |
5.6mm PVC/PE/LSZH |
2x (16*0.2mm CCA ) |
2.0mm PVC (Red,Black) |
5.05mm PVC/PE/ LSZH |
69±2 pF/m |
| RG59CCS +2x0.75, Figure 8 NO.7102044 |
0.643mm (SOL) CCS 252.83 Ω/km |
Foam FEP |
1.AL Foil 2.AL wire |
6.00mm PVC/PE/LSZH |
2x (16*0.25mm CCA ) |
2.0mm PVC (Red,Black) |
5.05mm PVC/PE/ LSZH |
69±2 pF/m |
| Construction Parameters: | ||||||||
| Inner Conductor | 0.70mm Bare Copper | |||||||
| Dielectric | 0.144"/3.66±0.05mm Foamed Polyethylene | |||||||
| Shield | 0.12mm BC-Braid(47%) | |||||||
| Jacket | 0.236"/6.00±0.1mm PVC/PE/LSZH | |||||||
| Power Wire Conductor | 2x(24*0.15mmBC ) | |||||||
| Power wire Diameter of insulation | 0.075"/1.9mmHDPE (Red,Black) | |||||||
| Jacket | 5.05mm PVC/PE/LSZH | |||||||
| Application | For Use in Longer CCTV Run Lengths | |||||||
| Electrical Characteristics: | ||||||||
| Inner Conductor Resistance | 54 Ohms/KM at 20℃ | |||||||
| Capacitance | 52 ±3 pF/m 17±0.3 pF/ft | |||||||
| Impedance | 75 ± 3 Ω | |||||||
| Return loss | between 5 and 1000MHz: > 22dB | |||||||
| Velocity of Propagation | 0.85 | |||||||
| Sparker Test (VAC) | 4 | |||||||
| Mechanical and Envrionmental Properties | ||||||||
| Cable bend radius | 10 times the cable diameter | |||||||
| Operating Temp Range | -20 ℃ to 60℃ | |||||||
| Cable diamensions | 6.0×5.05mm | |||||||
| Cross Section | ||||||||
 |
||||||||
| Attenuation(20℃): | ||||||||
| Frequency (MHZ) | Max Attenuation(dB/100ft) | Max Attenuation (dB/100m) | ||||||
| 5 | 0.82 | 2.50 | ||||||
| 10 | 0.92 | 2.80 | ||||||
| 50 | 2.13 | 6.50 | ||||||
| 100 | 2.92 | 8.90 | ||||||
| 200 | 4.20 | 12.80 | ||||||
| 400 | 6.07 | 18.50 | ||||||
| 700 | 7.51 | 22.90 | ||||||
| 900 | 8.79 | 26.80 | ||||||
| 1000 | 9.25 | 28.20 | ||||||
| Order Informations: | ||||||||
| Marking | HELLOSIGNAL RG59K + 2C0.5 Figure 8 CCTV COAXIAL CABLE 7102035 ×××M/FT |
|||||||
| Package | Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet … | |||||||
| Delivery time | Normally 25 days after received the deposit. | |||||||
| Brand | HELLOSIGNAL®OR OEM | |||||||
