Simplex SM Fiber Optic Patch Cord - SC/APC 5.0mm
G657A2 OS2 9/125μm · Bend-Insensitive · HDPE/LSZH Jacket · Ideal for FTTH & Access Networks
Insertion Loss ≤0.3 dB
Return Loss ≥60 dB
G657A2 Bend-Insensitive
LSZH Flame Retardant
Technical Specifications
| Parameter | Specification |
|---|
| Connector Type | SC/APC (Green Housing, Green Boot) |
| Fiber Type | G657A2 Single Mode OS2 9/125μm |
| Core Count | Simplex (1 Fiber) |
| Insertion Loss | ≤0.3 dB (IEC Grade C) |
| Return Loss | ≥60 dB (APC) |
| Cable Diameter | 5.0±0.2 mm |
| Outer Sheath | HDPE (Black) |
| Inner Sheath | LSZH (Black) |
| Wavelength | 1310/1550 nm |
| Min Bending Radius | 10D (Static) / 20D (Dynamic) |
| Tensile Strength | 100N (Long) / 350N (Short) |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +70°C |
| Standard | ANSI/TIA/EIA 568-C.3, IEC 61300-3-35 |
Buyer Pain Points & Our Solutions
| Pain Point | Our Solution |
|---|
| Signal loss from tight bending | G657A2 bend-insensitive fiber maintains stable transmission |
| Harsh indoor/outdoor environment | HDPE outer sheath resists weather and abrasion |
| Fire safety concern | LSZH inner sheath is low smoke zero halogen and flame retardant |
| Difficult stripping and splicing | Novel flute design enables easy strip and splice |
| Electromagnetic interference | Dual parallel FRP strength members resist EMI and crushing |
| Heavy and impractical installation | Simple structure and light weight improve practicality |
Product Overview
The Simplex SM Fiber Optic Patch Cord is a tight/semi-tight buffered fiber cable with SC/APC connectors pre-terminated on both ends. When utilized properly, it allows light signal transmission with minimal return loss and low attenuation, making your network more reliable. Manufactured from superior quality materials, this 9/125 OS2 single mode fiber optic cable is ideal for connecting 1G, 10G, 40G, 100G, and 400G Ethernet connections. It can transport data for up to 10km at 1310nm, or up to 40km at 1550nm.
The cable features a bend-insensitive G657A2 fiber protected by a black HDPE outer sheath and a black LSZH inner sheath, delivering excellent mechanical and environmental performance. A novel flute design makes stripping and splicing fast and easy, while two parallel FRP strength members provide strong resistance against electromagnetic interference and crushing, ensuring long-term stability in demanding FTTH and access network deployments.
Key Features
- Good Mechanical and Environmental Characteristics: Robust construction withstands challenging installation conditions.
- Simple Structure and Light Weight: High practicability with easy handling and deployment.
- Low Smoke Zero Halogen Sheath: Flame retardant LSZH inner sheath meets indoor fire safety requirements.
- Novel Flute Design: Easily strip and splice for simple installation and maintenance.
- Dual FRP Strength Members: Two parallel FRP members ensure anti-electromagnetic and crush resistance.
- Low-Bend-Sensitivity Fiber: Special fiber provides high bandwidth and excellent communication transmission.
Applications
This simplex patch cord is the ideal solution for FTTH indoor fiber patch cabling and is widely used in access networks, LAN (Local Area Network), fiber optic communication systems, FTTH (Fiber to The Home) indoor buildings, and optical fiber connection and transmission equipment. It delivers stable, low-loss connectivity across a broad range of telecom and broadband applications.
Packaging & OEM Service
This easily taken and well-protected fiber patch cable package is labelled and marked by OMC as default. Standard carton sizes are 34*22*15 cm, 44*34*24 cm, and 54*39*34 cm, with the carton selected based on goods quantity. Packing can be fully customized to your requirements.
OEM service is available for cable color, printing word, cable jacket material, connector color, OEM label, identify ring, cable label, box, and shipping marks. Different quality levels can be provided to match your project needs.
