Name: NO.7112362 U/UTP CAT 6A 26AWG STR CABLE-UL CMP - Premium Thin Network Cable for Enhanced Connectivity
Brand: HANGZHOU ZION COMMUNICATION CO., LTD
SKU: U/UTP CAT 6A
Availability: InStock

Detail Information

Highlight:

Enhanced Connectivity Network Cable

CAT 6A Network Cable

Premium Thin Network Cable

Product Description

U/UTP CAT 6A 28AWG STR CABLE-UL CMP
Key Information & Construction
SKU			7112361
UL Certificate Number:			E541136
Standards:			UL 444 & CSA C22.2 No.214 Communications Cables
Conductor Material:			Stranded Bare Copper/Tinned Copper
Conductor Size:			28AWG/ 7×0.005" / 7×0.127mm
Pairs:			4 Pairs
Insulation:			0.0236" / 0.60±0.05 mm FEP
Insulation Colors:			Blue-White,Orange-White
			Green-White,Brown-White
Out Jacket:			Material: Plenum PVC
			Wall Thickness: 0.0157". Nom(0.4mm)
			OD:0.1377"±0.006“ (3.5±0.15mm)
Cross Section

Application Support
· 1000BASE-T , 1000BASE-TX,100BASE-T , 100BASE-TX,100VG-AnyLAN,ATM
· 1Volp,ISDN, Token, 100MTPPDM, Analogand Datavideo, POE Type1,2,3,4
Electrical Characteristics
DC Resistance			＜23.6 Ohms/100m @20℃
DC Resistance unbalance			4% @ 20℃
Mutual Capacitance			5.6 nF/100m
Characteristic Impedance			1 - 100 MHz : 100±15 Ohms
			101 - 200 MHz : 100±22 Ohms
			201 - 500 MHz : 100±32 Ohms
Max Frequency			500MHz
Capacitance Unbalance			330 pF/100m
NVP(传输速率)			≥ 65%
Delay Skew			≤ 44ns/100m
Working Voltage			Typically up to 48V
Rated Voltage(V RMS)			300V
PHYSICAL PROPERTIES
Pulling Tension(Max)			20 lbs (89 N)
Bend Radius(Min)			4 Times the cable diameter
Operating Temperature			-20 to 75 ℃ (-4 to 167℉)
Performance Characteristics
Frequency	Attenuation	NEXT (dB)	ACRF (dB)	PS.NEXT (dB)	PS.ACRF (dB)	RL (dB)	Delay (ns/100m)	Skew (ns/100m)
MHz	dB	dB/100m	ns/100m	ns/100m	dB	dB	dB/100m	dB/100m
1	4.05	74.30	72.30	67.80	64.80	20.00	570.00	45.0
4	7.41	65.27	63.27	55.76	52.80	23.00	552.00
8	10.35	60.75	58.75	49.74	46.70	24.50	546.73
10	11.55	59.30	57.30	47.80	44.80	25.00	545.38
16	14.60	56.24	54.24	43.72	40.70	25.00	543.00
20	16.34	54.78	52.78	41.78	38.80	25.00	542.05
25	18.29	53.30	51.33	39.84	36.80	24.30	541.20
31.25	20.48	51.88	49.88	37.90	34.90	23.60	540.44
62.5	29.23	47.36	45.36	31.88	28.90	21.50	538.55
100	37.31	44.30	42.30	27.80	24.80	20.10	537.60
150	46.17	41.66	39.66	24.28	21.28	17.47	536.94
200	53.77	39.78	37.78	21.78	18.80	18.00	536.55
250	60.58	38.33	36.33	19.84	16.80	17.30	536.28
300	66.82	37.14	35.14	18.26	15.30	16.80	536.08
350	72.63	36.14	34.14	16.92	13.92	14.31	535.92
400	78.10	35.27	33.27	15.76	12.80	15.90	535.80
450	83.29	34.50	32.50	14.74	11.70	13.37	535.70
500	88.25	33.82	31.82	13.82	10.80	15.20	535.61
※Note: The above transmission performance tor the 100M, 20±2℃ under the conditions tested.
Order Informations
Marking			HANGZHOU ZION 7112361 U/UTP CAT6 4PR 28AWG STRANDED 500MHZ E541136 (UL)C(UL) VERIFIED TO ANSI/TIA 568C.2 RoHS COMPLIANT ***FT


Inner Package			1000FT/Pull Box or Wooden Spool (or Per customer's request)
Outer Package			Pallet (or Per customer's request)
Delivery time			Normally 25 days after received the deposit.
Brand			HELLOSIGNAL® OR OEM
Online Service:
Wechat			+86 15088607575
Whatsapp			+86 15088607575
Email			info@zion-communication.com
OEM Customized Service:
Color			We can customized Jacket Color based on RAL Classic
Printing			We can customized printing words on jacket
Packing & Label			We can customized spool, carton & label design.

Tag:

Place of Origin:	CHINA
Brand Name:	Zion communication OR OEM
Certification:	CE, ROHS, VDE, UL
Model Number:	U/UTP CAT 6A

Minimum Order Quantity:	500
Packaging Details:	Carton
Delivery Time:	Normally 20 working days
Payment Terms:	T/T, L/C
Supply Ability:	500000pcs / Month
