8 Fibers OM4 MPO-LC Harness Cable 2.0mm Straight for High-Density Data Centers

Basic Information

Place of Origin:	CHINA
Brand Name:	HELLOSIGNAL® OR OEM

Minimum Order Quantity:	50pcs
Packaging Details:	10 PC / Plastic Bag
Delivery Time:	Normally 25 days after received the deposit.
Payment Terms:	T/T
Supply Ability:	no limit

Get Best Price Contact Now

Detail Information

Durability:	<0.3dBtypical Change, 200 Matings	Interchangeability:	≤0.2dB
Insert-pull Test:	500times, IL＜0.5dB	Tensile Strength:	>70N
Operating Temperature (℃）:	-40 To + 85°C
Highlight:	8 Fibers MPO-LC Harness Cable , OM4 MPO-LC Harness Cable , 2.0mm Fiber Optic Harness Cable

Product Description

8 Fibers MPO to LC OM4 Fiber Optic MPO-LC 2.0mm Straight Harness Cables

Zion Product Information

Zion Code: ZCM11A18HMAX
Zion Description: 8F MPO OM4 Fiber Optic MPO-LC 2.0mm Straight Harness Cables

The MPO connector is a multi-fiber push-on connector designed for high-density environments. These connectors are widely used in data centers, fiber-to-the-building applications, and internal connections within optical transceiver equipment supporting 40G, 100G, and QSFP+ technologies.

MPO connectors are standardized according to IEC 61754-7 specifications, which define core count, gender (male/female), and polarity (PC or APC).

These 8-core MPO to Duplex (4xLC uniboot) or Simplex (4xLC) straight harness cable assemblies are optimized for direct connections between 40G QSFP+ PLR4 and 10G SFP+ LR optics in high-density data center applications.

Connector Standards & Specifications

MPO Singlemode

Reference: IEC 61754-7
Housing Details: SM APC: Green connectors + black boot (Standard Loss MPO)
SM APC: Yellow connectors + black boot (Super Low Loss MPO)

MPO Multimode

Reference: IEC 61754-7
Housing Details:
OM1 & OM2 PC: Beige connectors + black boot (Standard Loss MPO)
OM3 & OM4 PC: Aqua connectors + black boot (Standard & Super Low Loss MPO)
OM3 & OM4 PC: Heather Violet connectors + black boot (Standard Loss MPO)

Compliance Standards:

IEC 61754-7, IEC 61755, Telcordia GR-1435-CORE, JIS C5982, TIA-604-5 (FOCIS5)
Structured cabling per TIA-568-C
10G Fiber Channel Compliant
40G and 100G IEEE 802.3

Other Connector Standards

SC: TIA/EIA, FOCIS3, GR-326, NTT-SC, IEC 61754-4, JIS C5973
LC: TIA/EIA, FOCIS10, GR-326, EIA/TIA-604-10, IEC 61754-20, JIS C5973
FC: EIA/TIA-604-04, FOCIS4, NTT-FC, GR-326, IEC 61754-13, JIS C5973
ST: TIA/EIA, FOCIS2, GR-326, IEC 61754-2, JIS C5973
E2000: IEC 61754-15

Available Fiber Types

G657A1 MPO-LC, MPO-SC, MPO-FC, MPO-ST, MPO-E2000
G657A2/B2 MPO-LC, MPO-SC, MPO-FC, MPO-ST, MPO-E2000
G657B3 MPO-LC, MPO-SC, MPO-FC, MPO-ST, MPO-E2000
OM1 62.5/125 MPO-LC, MPO-SC, MPO-FC, MPO-ST, MPO-E2000
OM2 50/125 MPO-LC, MPO-SC, MPO-FC, MPO-ST, MPO-E2000
OM3 50/125 MPO-LC, MPO-SC, MPO-FC, MPO-ST, MPO-E2000
OM4 50/125 MPO-LC, MPO-SC, MPO-FC, MPO-ST, MPO-E2000
OM5 50/125 MPO-LC, MPO-SC, MPO-FC, MPO-ST, MPO-E2000

Optical Performance Specifications

Insertion Loss (MPO)

Singlemode (APC 8-degree polished):
Standard loss: ≤0.75dB (max), ≤0.50dB (typical)
Super Low loss: ≤0.35dB (max), ≤0.20dB (typical)

Multimode (PC Flat polish):
Standard loss: ≤0.6dB (max), ≤0.50dB (typical)
Super Low loss: ≤0.35dB (max), ≤0.20dB (typical)

Insertion Loss (LC/SC/FC/ST)

Single mode (APC 8-degree polished): ≤0.3dB
Multimode (PC Flat polish): ≤0.3dB

Return Loss (MPO)

Singlemode (APC 8-degree polished): ≥60dB
Multimode (PC Flat polish): ≥25dB

Return Loss (LC/SC/FC/ST)

APC: ≥60dB
UPC: ≥50dB
Multimode: ≥35dB

Additional Specifications:

Durability: <0.3dB typical change (200 matings)
Interchangeability: ≤0.2dB
Insert-pull Test: 500 times, IL <0.5dB
Tensile strength: >70N
Operating Temperature (Singlemode APC): -40°C to +85°C

Product Features

Low insertion loss, high return loss
MT-based multi-fiber connector supporting 4, 8, 12 and 24 fiber terminations
Economical solution for mass-termination of fiber
Designed for low loss and standard loss SM and MM applications
Ruggedized round cable, oval cable and bare ribbon options
Color-coded housings for easy identification of fiber type, polish type, and connector grade
Excellent repeatability and exchangeability

MTP/MPO Patch Cable Advantages

High Quality: Factory pre-terminated, tested and packaged with test reports for documentation and quality control
Space Saving: Small diameters reduce cable volume and improve air-conditioning in data centers
Time Efficient: Plug and play design reduces installation time

Applications

These SM 8F MPO-LC/SC/FC/ST Straight Harness Cables are optimized for:

40G QSFP+ PLR4 to 10G SFP+ LR optics direct connections
High-density data center applications
Direct connections between QSFP+ and (4) SFP+ ports without patch panels or intermediate trunks
High-density data center environments
Fiber-to-the-building applications
Internal connections within fiber optic equipment

Connection Methods & Polarity

MPO-8 x LC Simplex Structure - Type 1

MPO-4 x LC Duplex Structure - Type 2

MPO-4 x Uniboot LC Structure - Type 3

Material Details

Packaging & Customization

Standard Packaging: Well-protected fiber optic cable packages labeled and marked by OMC as default.

Carton Sizes: 34×22×15 cm; 44×34×24 cm; 54×39×34 cm (selected based on quantity)

Customization Available:

Cable color, printing, jacket material, connector colors
OEM labels, identification rings, cable labels, boxes, shipping marks
Different quality levels
