12 Fibers MPO OM4 Fiber Optic Loopback Module for 40/100G Network Testing

The MPO loopback contains MPO back ring jumping lines in the LOOPBACK configuration, with both ends of the fiber terminated into an MPO connector to create a light path within the same connector. This enables testing of device launch capacity and receiving sensitivity, particularly in 40/100G network communications. By returning signals, it helps locate various potential issues and enables effective testing and evaluation of individual components or interfaces within fiber optic networks.

Optical fiber loopback circuits are available in multiple configurations to accommodate 8-core, 12-core, and 24-core MPO connectors with various fiber configurations for comprehensive port testing. The 12F MPO Fiber Loopback Module specifically allows verification and testing of transceivers featuring MPO interfaces for 40GBASE-SR4 QSFP+ or 100GBASE-SR4 devices.

MPO Loopback modules provide a looped signal to test transmit and receiving functions. They are widely used within testing environments, especially in parallel optics 40G and 100G networks. Loopbacks are engineered to link Transceivers (TX) and Receivers (RX) positions of MPO transceiver interfaces. MPO loopbacks facilitate and accelerate insertion loss (IL) testing of optical network segments when connected to MPO trunks and patch leads.

MPO Singlemode Reference: IEC 61754-7
MPO Singlemode Housing Details: SM APC: Green connectors+black boot (Standard Loss MPO)
SM APC: Yellow connectors+black boot (Super low loss MPO)

MPO Multimode Reference: IEC 61754-7
MPO Multimode Housing Details:
OM1&OM2 PC: Beige connectors+black boot (Standard Loss MPO)
OM3&OM4 PC: Aqua connectors+black boot (Standard&Super low loss MPO)
OM3&OM4 PC: Heather Violet connectors+black boot (Standard loss MPO)

A loopback test involves sending a signal from a communication device and looping it back to the same device to verify proper functionality or troubleshoot defective network nodes. For fiber optic loopback testing, optical loopbacks verify the operational reliability of devices. Using fiber optic loopback cables or modules for data transmission, the signal emitted by the device is looped from the transmit (Tx) end back to the receive (Rx) end of the same component.

12F MPO-LC/SC/FC/ST Straight harness cables are designed for 40G LR4 PSM, 40GBASE-SR4, 40G QSFP+ PLR4 and high-density data center applications. Optimized for 10/40/100G high-density data center requirements.

When selecting a loopback for transceiver testing, consider connector type, polish type, and cable type compatibility. The following tables provide selection guidance for commonly used transceiver modules.

This guide discusses specific fiber loopback choices for the most commonly used fiber optic transceivers. For transceiver modules not mentioned here, suitable loopbacks can be selected by understanding their interface type, physical contact requirements, and cable specifications.
