Name: CAT7 Industrial Automation Cables AL / Mylar Screen And Copper Wire Braid
Brand: HANGZHOU ZION COMMUNICATION CO., LTD
SKU: Industrial CAT7 Cable
Availability: InStock

CAT7 Industrial Automation Cables AL / Mylar Screen And Copper Wire Braid

Basic Information

Place of Origin:	China
Brand Name:	Zion communication OR OEM
Certification:	CE, RoHS, VDE, UL
Model Number:	Industrial CAT7 Cable

Minimum Order Quantity:	10 KM
Packaging Details:	500FT/PULL BOX, 1000FT/Wooden Spool,Pallet
Delivery Time:	25 working days
Payment Terms:	T/T, L/C
Supply Ability:	1000KM / Month

Get Best Price Contact Now

Detail Information

Conductor:	Solid Or Stranded Copper Wire	Insulation:	PO
Shield:	AL/Mylar Screen And Copper Wire Braid	Jacket:	See Attached List
Color:	Grey(similar To RAL 7035)
Highlight:	automation cables , high flex industrial ethernet cable

Product Description

Industrial Ethernet Cable

https://www.zion-communication.com/Industrial-Ethernet-Cable-pl569518.html

Industrial CAT7 Cable


▉ Application
Apply to complex industrial environment,power chain and moving mechanical components,used in electric power transportation, water treatment and other industries.At the same time, cable suitable for EtherCAT and Ethernet/IP system using.

▉ Cable Construction
Conductor: Stranded copper wire
Insulation: PO
Shield: AL/Mylar screen and copper wire braid
Jacket: see attached list
Color: grey(similar to RAL 7035)

▉ Product Feature
Professional design,reduce the using cost
PUR jacket is resistant to oil,abrasion and hydrolysis
Fire resistance meets IEC60332-1
Easy bending
UV resistance
Double shielded cable,excellent Anti-EMI performance and reliable transmission

▉ Cross Section

▉ Technical data
Temperature range		.-40℃ to 80℃
Test voltage		1000V
Peak voltage		(Data transmission application) 100V
Characteristic impedance 100±15 Ohm		100±15 Ohm
Min bending radius		Fixed installation:8x cable diameter
		Occasional movement:15x cable diameter
Other characteristics		According to ANSI/TIA-568 and IEC11801

▉ Product List
Item No.	Spec.	Jacket	Nominal OD(mm)	Copper.weight approx (kg/km)	Weight approx(kg/km)
7130300	42AWG26/7	PVC	6.4	25	49
7130301	42AWG26/7	PUR	6.4	25	47
7130302	42AWG24/7	PVC	7.8	40	74
7130303	42AWG24/7	PUR	7.8	40	72

▉ Order Informations
Marking		HELLOSIGNAL Industrial CAT7 Cable XXXFT/M
Package		500FT/PULL BOX, 1000FT/Wooden Spool,Pallet …
Delivery time		Normally 25 days after received the deposit.
