FC UPC Female to FC UPC Male Plug-In Fixed Fiber Optical Attenuator with 1-25dB Range and Low Insertion Loss

FC UPC Female to FC UPC Male Plug-In Fixed Fiber Optical Attenuator with 1-25dB Range and Low Insertion Loss
FC UPC Female to FC UPC Male Plug-In Fixed Fiber Optical Attenuator with 1-25dB Range and Low Insertion Loss
Basic Information
Place of Origin: CHINA
Brand Name: HELLOSIGNAL® OR OEM
Minimum Order Quantity: 50pcs
Packaging Details: 10 PC / Plastic Bag
Delivery Time: Normally 25 days after received the deposit.
Payment Terms: T/T
Supply Ability: no limit
Get Best Price Contact Now
Detail Information
Mating Durability（cycle）: ≥1000 Response Time(dB/ms): 3
Attenuation Control Accuracy(dB): ±0.5 Supply Voltage(DC): ± 5V
Operating Temperature (℃）: -5 ~ +65 Storage Temperature (℃）: -40 ~ +75
Highlight:

Fiber Optic Attenuator Plug In

,

FC UPC Fiber Optical Attenuator

,

Fiber Optic Attenuator High Return Loss

Product Description

FC UPC Female to FC UPC Male Plug-In Fixed Fiber Optical Attenuator (1-25dB)
Precision fiber optic attenuator designed for reliable signal control in optical communication systems. Operating at 1310-1550nm wavelengths with attenuation range of 1-25dB.
FC UPC Female to FC UPC Male Plug-In Fixed Fiber Optical Attenuator with 1-25dB Range and Low Insertion Loss 0
Product Identification
Zion Code Zion Description
7236008 FC UPC Female to FC UPC Male Plug-in Fixed Fiber Optical Attenuator (1-25dB)
Female to male fixed attenuators from OMC offer defined control of optical signals in both integrated and add-on products. These precise attenuation levels provide highly accurate performance for your project or application requirements.
FC UPC Female to FC UPC Male Plug-In Fixed Fiber Optical Attenuator with 1-25dB Range and Low Insertion Loss 1
Key Features
  • Precise attenuation values
  • Low PDL and insertion loss
  • Precision reflection polishing
  • Fast connection capability
  • Stable attenuation with high reliability
  • Compliant with industry green initiatives including ROHS
  • GR910 compliant
Applications
ZION COMMUNICATIONS' Fiber Optic Attenuator reduces optical signal energy to prevent receiver distortion from excessive input power. This optical passive device is essential for debugging optical power performance, instrument calibration, and signal attenuation in optical communication systems.
Primary applications include:
  • CWDM & DWDM systems
  • Data center networks
  • CATV systems
  • Test equipment and calibration
FC UPC Female to FC UPC Male Plug-In Fixed Fiber Optical Attenuator with 1-25dB Range and Low Insertion Loss 2
Connector Types
Connector Type Description
FC UPC Female to FC UPC Male Plug-In Fixed Fiber Optical Attenuator with 1-25dB Range and Low Insertion Loss 3 FC UPC Female to FC UPC Male Plug-In Fixed Fiber Optical Attenuator with 1-25dB Range and Low Insertion Loss 4 LC optical fiber attenuator: Used in LC fiber interfaces with modular jack (RJ) latch mechanism. Commonly used in routers.
FC UPC Female to FC UPC Male Plug-In Fixed Fiber Optical Attenuator with 1-25dB Range and Low Insertion Loss 5 FC UPC Female to FC UPC Male Plug-In Fixed Fiber Optical Attenuator with 1-25dB Range and Low Insertion Loss 6 SC optical fiber attenuator: Applied to SC fiber interfaces, similar to RJ-45 but with copper column contacts.
FC UPC Female to FC UPC Male Plug-In Fixed Fiber Optical Attenuator with 1-25dB Range and Low Insertion Loss 7 FC UPC Female to FC UPC Male Plug-In Fixed Fiber Optical Attenuator with 1-25dB Range and Low Insertion Loss 8 FC optical fiber attenuator: Applied to FC fiber interfaces with metal sleeve and turnbuckle fastening. Typically used on ODF distribution frames.
FC UPC Female to FC UPC Male Plug-In Fixed Fiber Optical Attenuator with 1-25dB Range and Low Insertion Loss 9 FC UPC Female to FC UPC Male Plug-In Fixed Fiber Optical Attenuator with 1-25dB Range and Low Insertion Loss 10 ST optical fiber attenuator: Applied to ST fiber interfaces with round shell and turnbuckle fastening. Commonly used in fiber distribution frames.
Technical Specifications
Parameter FC, SC, LC, ST
Operating Wavelength (nm) 1310-1550
Insertion Loss (dB) ≤ 0.6
Return Loss (dB) ≥45
Repeatability (dB) ≤ 0.2
Resolution (dB) ≤ 0.1
Wavelength Dependent Loss (dB) WDL ≤ 0.3 (C+L Band)
Polarization Dependent Loss (dB) PDL ≤ 0.2
Temperature Dependent Loss (dB) TDL ≤ 0.2
Tolerance for 1-5dB Attenuation (dB) ±0.5
Tolerance for 6-30dB Attenuation (nm) ±10
Mating Durability (cycles) ≥1000
Response Time (dB/ms) 3
Attenuation Control Accuracy (dB) ±0.5
Supply Voltage (DC) ± 5V
Operating Temperature (°C) -5 to +65
Storage Temperature (°C) -40 to +75
Related Fiber Optic Attenuator Products
Zion Code Product Code Description
7237001 ZC11FXAADXX LC APC Female to LC APC Male Plug-in Fixed Fiber Optical Attenuator (1-25dB)
7237002 ZC11FXBBDXX LC UPC Female to LC UPC Male Plug-in Fixed Fiber Optical Attenuator (1-25dB)
7237003 ZC11FXCCDXX SC APC Female to SC APC Male Plug-in Fixed Fiber Optical Attenuator (1-25dB)
7237004 ZC11FXDDDXX SC UPC Female to SC UPC Male Plug-in Fixed Fiber Optical Attenuator (1-25dB)
7237005 ZC12FXEEDXX ST APC Female to ST APC Male Plug-in Fixed Fiber Optical Attenuator (1-25dB)
7237006 ZC11FXFFDXX ST UPC Female to ST UPC Male Plug-in Fixed Fiber Optical Attenuator (1-25dB)
7237007 ZC11FXGGDXX FC APC Female to FC APC Male Plug-in Fixed Fiber Optical Attenuator (1-25dB)
7237008 ZC11FXHHDXX FC UPC Female to FC UPC Male Plug-in Fixed Fiber Optical Attenuator (1-25dB)
7237009 ZC11FXIIDXX MU APC Female to MU APC Male Plug-in Fixed Fiber Optical Attenuator (1-25dB)
7237010 ZC12FXJJDXX MU UPC Female to MU UPC Male Plug-in Fixed Fiber Optical Attenuator (1-25dB)
7237011 ZC11FXKKDXX E2000 APC Female to E2000 APC Male Plug-in Fixed Fiber Optical Attenuator (1-25dB)
7237012 ZC11FXLLDXX E2000 UPC Female to E2000 UPC Male Plug-in Fixed Fiber Optical Attenuator (1-25dB)
7237013 ZC12FXMMDXX 8F MPO(Female) to MPO(Male) Fiber Optical Attenuator (1-20dB)
7237014 ZC11FXNNDXX 12F MPO(Female) to MPO(Male) Fiber Optical Attenuator (1-20dB)
7237015 ZC11FXOODXX 24F MPO(Female) to MPO(Male) Fiber Optical Attenuator (1-20dB)
FC UPC Female to FC UPC Male Plug-In Fixed Fiber Optical Attenuator with 1-25dB Range and Low Insertion Loss 11
Packaging
This easily handled and well-protected fiber optic cable package is labeled and marked by OMC as default. Standard carton sizes: 34×22×15 cm; 44×34×24 cm; 54×39×34 cm. Carton selection depends on product quantity. Custom packaging available.
FC UPC Female to FC UPC Male Plug-In Fixed Fiber Optical Attenuator with 1-25dB Range and Low Insertion Loss 12
OEM/ODM Services
OMC's LC Female to LC Male Fixed Attenuators are available for SM UPC (1-25dB) and SM APC (1-25dB)
ZION Communication has extensive experience in producing OEM/ODM cases with our professional R&D team.
  • Customized logo application
  • Label/PE bag/carton design services
