16 Core Fiber Optical Terminal Box with ABS+PC Material and Mini PLC Splitter for Fttx Network

16 Core Fiber Optical Terminal Box with ABS+PC Material and Mini PLC Splitter for Fttx Network
16 Core Fiber Optical Terminal Box with ABS+PC Material and Mini PLC Splitter for Fttx Network
16 Core Fiber Optical Terminal Box with ABS+PC Material and Mini PLC Splitter for Fttx Network
Basic Information
Place of Origin: CHINA
Brand Name: Zion communication
Model Number: ZCFTB-16Q-1（7232038）
Minimum Order Quantity: no limit
Packaging Details: 10 PC / Plastic Bag
Delivery Time: Normally 10 working days
Payment Terms: T/T
Supply Ability: no limit
Get Best Price Contact Now
Detail Information
Color: White、Grey Capacity: 16 Core
Material: ABS、ABS+PC PLC Splitter Type: Mini PLC Splitter
Dimension(L*W*D,MM): 360*334*131 Weight(KG): 2.4
Highlight:

fiber optical terminal box

,

fiber termination box

Product Description

Fiber Optical Terminal Box - ZCFTB-16Q-1 (7232038)
High-performance fiber optical terminal box with 16-core capacity, designed for FTTx network applications. Features IP55 protection level and supports Mini PLC Splitter integration.
Technical Specifications
Model No. ZCFTB-16Q-1 (7232038)
Color White, Grey
Capacity 16 core
Protection Level IP55
Material ABS, ABS+PC
Flame Retardant Performance Non-flame retardant
PLC Splitter Type Mini PLC Splitter
Dimension (L*W*D, MM) 360*334*131
Inner Box Size (MM) 365*340*135
Outer Box Size (MM) 690*380*355
Weight (KG) 2.4
Gross Weight (KG) 13
PCS/Carton 5
Product Overview
ZION COMMUNICATION Model ZCFTB-16Q-1 serves as the termination point in FTTx networks, connecting drop cables with feeder cables to accommodate at least 16 users. Provides optimal space for splicing, splitting, storage, and cable management operations.
Product Images
16 Core Fiber Optical Terminal Box with ABS+PC Material and Mini PLC Splitter for Fttx Network 0
16 Core Fiber Optical Terminal Box with ABS+PC Material and Mini PLC Splitter for Fttx Network 1
16 Core Fiber Optical Terminal Box with ABS+PC Material and Mini PLC Splitter for Fttx Network 2
Packaging Information
  • Plastic bag size: 360×334×131mm
  • Inner box with single corrugated size: 365×340×135mm
  • Carton with double corrugated size: 690×380×355mm (5PCS/Box)
  • Weight per carton: 13KG
Transportation & Storage Guidelines
Protect products from rain, direct sunlight, and compression during transportation. Store in warehouse conditions avoiding moisture, sunlight, and fire sources. Maintain storage temperature between 25℃ and +40℃.
Special parts that are easily damaged during transportation should be protected carefully.
