48 Cores IP68 PC+ABS Fiber Optic Splice Closure for Horizontal Cable Protection

48 Cores IP68 PC+ABS Fiber Optic Splice Closure for Horizontal Cable Protection
48 Cores IP68 PC+ABS Fiber Optic Splice Closure for Horizontal Cable Protection
48 Cores IP68 PC+ABS Fiber Optic Splice Closure for Horizontal Cable Protection
Basic Information
Place of Origin: CHINA
Brand Name: Zion communication
Model Number: ZCSC-H048-08（7231107）
Minimum Order Quantity: no limit
Packaging Details: 10 PC / Plastic Bag
Delivery Time: Normally 10 working days
Payment Terms: T/T
Supply Ability: no limit
Get Best Price Contact Now
Detail Information
Color: Black Capacity: 48 Cores
Material: PP、PC，PC+ABS Inlet/outlet: 3+3
Dimension(L*W*D,MM): 297.5*197*78
Highlight:

Fiber Optic Horizontal Splice Closure

,

PC Horizontal Fiber Optic Splice Closure

,

ZCSC-H048-08 （7231107）

Product Description

PC ABS Fiber Optic Horizontal Splice Closure - ZCSC-H048-08 (7231107)
Product Overview

ZION COMMUNICATION Model No. ZCSC-H048-08 is a primary equipment unit for user access points, designed for protective connection and distribution between two or more cables. Its main function is to connect distribution cable and indoor cable in outdoor environments. Widely used in communication systems, cable TV, and optical cable network systems due to its stable structure, excellent sealing performance, and ease of installation.

Technical Specifications
Model No. ZCSC-H048-08 (7231107) 48 Cores IP68 PC+ABS Fiber Optic Splice Closure for Horizontal Cable Protection 0
Color Black
Capacity 48 cores
Protection Level IP68
Material PP, PC, PC+ABS
Sealing Method For Inlets Mechanical seal
Inlet/Outlet 3+3
Inlet Cable Port Ф13, Ф16, Ф20
Outlet Cable Port Ф13, Ф16, Ф20
Dimensions (L*W*D, MM) 297.5*197*78
Inner Box Size (MM) 300*200*95
Outer Box Size (MM) 595*425*515
Unit Weight (KG) 1.38
Gross Weight (KG) 14.5
Units per Carton (PCS) 10
Packaging Information
  • Plastic bag size: 297.5*197*78mm
  • Inner box with single corrugated size: 300*200*95mm
  • Carton with double corrugated size: 595*425*515mm (10PCS/Box)
  • Weight per carton: 14.5KG

Note: Special parts that are easily damaged during transportation should be protected carefully.
