Home > Products> Optical Fiber System> SC UPC Simplex G.652.D Single Mode 6ft Fiber Optic Patch Cord Yellow PVC Jacket

SC UPC Simplex G.652.D Single Mode 6ft Fiber Optic Patch Cord Yellow PVC Jacket

Basic Information

Place of Origin:	CHINA
Brand Name:	Zion communication OR OEM
Certification:	ISO, CE, RoHS, UL
Model Number:	SC UPC Simplex G.652.D

Minimum Order Quantity:	1,000 PCS
Packaging Details:	1 PC/Plastic Bag, PCS/Carton
Delivery Time:	Normally 25 workingdays
Payment Terms:	T/T,L/C
Supply Ability:	30,000 PCS / Month

Get Best Price Contact Now

Detail Information

Fiber Unit:	G.652D Or G.657A	Tight Buffer Fiber:	Tight Buffer Fiber
Jacket:	PVC Or LSZH	Color:	Yellow
Package:	1 PC/Plastic Bag, PCS/Carton
Highlight:	G.652.D SC UPC Simplex , SC UPC Simplex Single Mode , 6ft SC UPC Patch Cord

Product Description

SC UPC Simplex G.652.D Single Mode 6ft FOPT Yellow Color

High-performance fiber optic patch cord featuring SC UPC connectors and G.652.D single mode fiber in a durable PVC jacket.

Product Specifications - Fiber Optic Cable

Fiber Type	Single-mode: OS2 (G.652.D / G.657.A1 / G.657.A2) Multi-mode: OM1(62.5/125), OM2(50/125) OM3, OM4 (50/125, Laser Optimization)
900um/0.9mm Buffer Color	Yellow: SM: OS2 (G.652.D / G.657.A1 / G.657.A2) Orange: OM1, OM2 Aqua: OM3, OM4 Customized: Green, Brown, White, Red, Black, Purple, Rose, Slate
900um/0.9mm Types	Single Typical: 1 Fiber Bunch Typical: 12 Fibers Customized: 4-48 Fibers
Aramid Yarn (2.0/3.0mm)	Aramid yarn is laid over the cable core to serve as peripheral strength member.
Cable Jacket	Main material: PVC / LSZH / Plenum (OFNP) OD: Simplex: 0.9/2.0/3.0mm Duplex: 0.9/2.0/3.0mm
Jacket Color	Yellow: SM: OS2 (G.652.D / G.657.A1 / G.657.A2) Orange: OM1, OM2 Aqua: OM3, OM4
Cable Length	1m, 2m, 3m. Other lengths on request

Product Specifications - Connector

Connector Type

LC, SC, FC, ST, MU, MTRJ, LSH, E-2000

SC (Subscriber Connector/Square Connector/Standard Connector)
Typical Application: Telecom, GPON, EPON, GBIC

Product Specifications - Performance Parameters

Parameter	SC UPC SM(OS2) G.652.D/G.657.A1/G.657.A2
Operating Wavelength (nm)	1310-1550
Insertion Loss (dB)	≤ 0.3
Return Loss (dB)	≥ 55
Repeatability (dB)	≤ 0.1
Interchangeability (dB)	≤ 0.2
Tensile Strength (N)	≥ 1000
Operating Temperature (°C)	-20 to +85
Storage Temperature (°C)	-40 to +85

Product Code

Zion Code	Description
21F1111-2	SC UPC Simplex G.652.D Single Mode PVC 0.9mm -2m(6ft) FOPT

OEM/ODM Services

ZION Communication has rich experiences in producing OEM/ODM cases because of our professional R&D team.

Customized Logo
Printing on Cable
Label/PE bag/Carton design
Different Color & Different Lengths Available
