1 Pair LSZH Green Jacket 0.8mm Bare Copper KNX Control Cable for Lighting and Security Systems

Basic Information

Place of Origin:	China
Brand Name:	Zion communication OR OEM
Certification:	CE, RoHS, VDE, UL
Model Number:	Flexible Control Cable

Minimum Order Quantity:	10 KM
Packaging Details:	500FT/PULL BOX, 1000FT/Wooden Spool,Pallet
Delivery Time:	25 working days
Payment Terms:	T/T,L/C
Supply Ability:	1000KM / Month

Get Best Price Contact Now

Detail Information

Conductor:	Bare Copper,(1/0.8mm)	Insulation:	Polyethylene (PE)
Fillers:	Cotton Thread	Overall Tape:	Polyester
Drain Wire:	Tinned Copper (7/0.16mm)	Overall Screen:	Overall Aluminium Foil (100% Coverage)
Sheath Material:	Low Smoke Halogen Free (LSHF)
Highlight:	Green Jacket Knx Cable , 1 Pair Knx Cable , 1mm Knx Cable

Product Description

1 Pair LSZH Green Jacket 1mm KNX Cable

POWER & CONTROL CABLE

View Power and Control Cables Catalog

Technical Datasheet (NO.KNX1P08)

Cable Construction

Conductor Material	Bare Copper (1/0.8mm)
Pairs Insulation Material	Polyethylene (PE)
Number of Pairs	1
Fillers	Cotton Thread
Overall Tape	Polyester
Drain Wire	Tinned Copper (7/0.16mm)
Overall Screen	Overall Aluminium Foil (100% Coverage)
Sheath Material	Low Smoke Halogen Free (LSHF)
Sheath Colour	Green
Core Identification	Red, Black

Cross Section

Application Support

Used for lighting control, blind control, air-conditioning, heating and security systems. ZION Certified products communicate with each other to ensure smooth functioning and easy expansion of systems, creating comfortable, efficient and safe environments.

Electrical Characteristics

Nominal Conductor Resistance	< 38.5 Ω/km
Insulation Resistance	> 200MΩ.M
Voltage Rating	450/750V (Applies to CE marked FS C branded stock only)
Test Voltage	2.5kV for 5 minutes

Physical Characteristics

Overall Diameter	5.6 ± 0.2mm
Min Bend Radius	10 x OD
Temperature Rating	-10°C to +70°C
Weight	40 kg/km

Standards Compliance

Flame Retardant	BS EN 60332-1-2
Low Smoke Generation	BS EN 61034-2
Halogen Gas Emission	BS EN 60754-1&2
RoHS3 Compliant	Yes
CE Compliant	LVD (2014/35/EU), CPR (305/2011)
CPR Classification	Eca (EN50575:2014+A1:2016)

Order Information

Marking	HELLOSIGNAL NO.KNX1P08 KNX CABLE LSZH 001--300M
Inner Package	300M/Wooden Spool
Outer Package	Color Box, Pallet (or Per customer's request)
Delivery Time	Normally 25 days after received the deposit
Brand	HELLOSIGNAL® OR OEM
