SC APC Simplex OM1 Multimode PVC 0.9mm Fiber Optic Patch Cord for High-Speed Data Transmission

Basic Information

Place of Origin:	CHINA
Brand Name:	Zion communication OR OEM
Certification:	ISO, CE, RoHS, UL
Model Number:	SC APC Simplex OM1

Minimum Order Quantity:	1,000 PCS
Packaging Details:	1 PC/Plastic Bag, PCS/Carton
Delivery Time:	Normally 25 workingdays
Payment Terms:	T/T,L/C
Supply Ability:	30,000 PCS / Month

Get Best Price Contact Now

Detail Information

Fiber Unit:	G.652D Or G.657A	Tight Buffer Fiber:	Tight Buffer Fiber
Jacket:	PVC Or LSZH	Color:	Orange
Package:	1 PC/Plastic Bag, PCS/Carton
Highlight:	Orange OM1 SC APC Simplex , Multimode SC APC Patch Cord , FOPT SC APC Patch Cord

Product Description

SC APC Simplex OM1 Multimode PVC 0.9mm 2m Fiber Optic Patch Cord

High-performance fiber optic patch cord featuring SC APC connectors, OM1 multimode fiber, PVC jacket, and 0.9mm diameter in a 2-meter length.

Product Specifications

Fiber Optic Cable

Fiber Type

OM1 Multimode (62.5/125)

Orange jacket color

Single fiber configuration

2-meter length

0.9mm diameter

PVC jacket material

Zion Code: 22F1411-2

Available in custom lengths

Custom colors available

4-48 fiber configurations available

Aramid yarn strength member

LSZH and Plenum options available

Duplex configurations available

Custom fiber counts available

Buffer Color

Orange (OM1, OM2)

Yellow (Single-mode)

Aqua (OM3, OM4)

Custom colors available

900um/0.9mm types

Single typical: 1 fiber

Bunch typical: 12 fibers

Customized: 4-48 fibers

Aramid yarn laid over cable core

PVC/LSZH/Plenum (OFNP) jacket

Simplex: 0.9/2.0/3.0mm

Duplex: 0.9/2.0/3.0mm

Standard lengths: 1m, 2m, 3m

Custom lengths available

Jacket Color

Orange (OM1, OM2)

Yellow (Single-mode)

Aqua (OM3, OM4)

Custom colors available

Cable Length

2 meters (6 feet)

Other lengths available on request

Standard lengths: 1m, 2m, 3m

Custom lengths available

Available in various diameters

Multiple jacket materials

Custom configurations available

OEM/ODM services available

Connector Type

SC APC

Also available: LC, FC, ST, MU, MTRJ, LSH, E-2000

Typical applications: Telecom, GPON, EPON, GBIC

Subscriber Connector/Square Connector/Standard Connector

High-performance connectivity

Reliable signal transmission

Industry-standard compatibility

Easy installation and maintenance

Durable construction

Wide temperature range operation

High tensile strength

Low insertion loss

High return loss

Excellent repeatability

Superior interchangeability

Performance Parameters

Operating Wavelength: 850-1300nm

Insertion Loss: ≤ 0.3 dB

Return Loss: ≥ 35 dB

Repeatability: ≤ 0.1 dB

Interchangeability: ≤ 0.2 dB

Tensile Strength: ≥ 1000 N

Operating Temperature: -20°C to +85°C

Storage Temperature: -40°C to +85°C

Reliable performance

Stable operation

Long service life

Industry compliance

Quality assurance

Performance testing

Standards compliance

OEM/ODM Services

Zion Communication offers comprehensive OEM/ODM services with our professional R&D team:

Customized Logo
Printing on Cable
Label/PE bag/Carton design
Different Color & Length Options
