|Place of Origin:||China|
|Brand Name:||Zion communication OR OEM|
|Certification:||ISO, UL, CE, RoHS|
|Model Number:||RG6 Coaxial Cable|
|Minimum Order Quantity:||30 KM|
|Packaging Details:||305M, 1000FT, Wooden Reel, Carton|
|Delivery Time:||25 working days|
|Payment Terms:||T/T, L/C|
|Supply Ability:||3000KM / Month|
|Conductor:||Bare Copper||Insulation:||Foamed PE|
|Shield:||Bare Copper Braiding||Jacket:||CMR Rated PVC|
|Color:||Black, White||Package:||305M, 1000FT, Wooden Reel, Carton|
18 AWG Bare Copper Conductor RG6 Riser CMR Coaxial Cable for TV Antenna
Visit our official website to learn more about CATV Coaxial Cable
KT0697 RG6 Standard Shield Coaxial Cable 18 AWG BC 95% BC CMR Rated PVC
is a specific type of CATV coaxial cable , RG 6(Produced by Zion communication) is perfect for
digital Cable and Satalite, Attenas, and communication systems. RG 6 has a characteristic
impedance of 75 ohms. Zion communication using best raw material and best worker to produce
RG 6 to meet high performance in practical application. RG 6 is packed in 300M/1000FT/
1000M wooden spool, and will be layed on pallet to protect the spool and easier carry.
Because of good managing methods, Zion communication’s price of RG 6 is not high although
our quality is really high.
Suitable for RF signal transmission
■ Local Area Network
■ Digital video
|KT0697 RG6 Standard Shield 18 AWG Bare Copper 95% Copper Braiding CMR Rated PVC|
|Inner Conductor||0.040"/1.02mm/18AWG||Bare Copper|
|Dielectric||0.180"/4.57mm Foamed PE||Gas Expanded Polyethylene|
|Shield 1||0.187"/4.75mm||Bonded Aluminum Polyproylene|
|Shield 2||95% coverage||Copper Braid Wire|
|Jacket||0.297"±0.006"/6.80±0.10mm||PVC CMR (Riser)|
|Application||For Use in Longer CATV||Run Lengths|
|Inner Conductor Resistance||The Max. at 20℃ shall be||< 87 Ω/km ; < 26.6Ω/1000ft|
|Capacitance||52 ±3 pF/m||15.9 ±0.9 pF/ft|
|Impedance||75 ± 3 Ω|
|Return loss||between 5 and 1000MHz:||> 22dB|
|Velocity of Propagation||0.85|
|Sparker Test (VAC)||4|
|Mechanical and Envrionmental Properties:|
|Cable bend radius||10 times the cable diameter|
|Operating Temp Range (PVC)||-20 ℃ to 75℃|
|Cable diamensions||0.2988"±0.006''/6.80±0.10 mm PVC|
Zion communication KT0697 RG6 Bare Copper 95% Copper
PVC CMR CATV COAXIAL CABLE ×××M/FT
|Package||500FT/Pull Box, 1000FT/Wooden Spool/Pallet|
|Delivery time||Normally 25 days after received the deposit.|
|More informations||Please contact with us.|
1, From raw materials to final products, we perform intense quality checks to maintain our product quality:
A, Incoming material inspected by QC.
B, Manufacturing Process Control
C: Workers trained daily/weekly/monthly
D: Work instructions manual at each work station
E: 5S system implemented
F: Machine maintenance procedure
G: Quality Control and Final Inspection
The QC staff will check the material, process product
and final product according to the specification or test procedure.
2, Our R&D efforts center on reinforcing and developing element technologies
needed to support the future growth and success for customers and Zion communication.
3, We know customers have urgent needs.
We are skilled at effective communication to interact with customers.
In order to provide prompt service, we can answer for you 7*24 hours.
4, We can Quickly and professionally answer for the inquire
5, More than 1000 kinds of cable, connectors and assembles can be produce and organized from us
6, Intime delivery
